EXTRALINK Agnes 2 Core Fiber Optic Termination Box, White (EL-TERMTB-2CFO)

Kodas: EL-TERMTB-2CFO
ID: #1710

Light weight, small size, made of high class engineering plastic ABS

naujiena

0.44€ su PVM

Kaina be PVM: 0.36€

  Turime sandėlyje
Kiekis:


Produkto savybės:

- Light weight, small size and easy installation
- Made of high class engineering plastic ABS
- Special fiber routing designs to ensure the bending radius greater than 40mm
- Adopting the splice trays for easy operations

Produkto specifikacijos:

Applicable for: φ8-φ10.5mm outdoor cable
Optical fiber diameter: 125μm ( 652 & 657 )
Tight buffer diameter: 250μm & 900μm
Fiber mode: Single & multi mode
Adapter: SC & FC
Insert loss: ≤ 0.2dB(1310nm & 1550nm)
Input: 2

Working temperature: -20°C ~ 70°C
Relative humidity: ≤85%(+30°C)
Atmospheric pressure: 70kPa ~106kPa
Dielectric strength: ≥3000V DC 1min, no spark-over and no flying arc
Insulation resistance: ≥1000MΩ/500V DC
