EXTRALINK ARES pilnai GIGABIT valdomas POE komutatorius/šakotuvas 16 lizdų 10/100/1000M TX su POE, CONSOLE PORT,ir 2X GE SFP(EL-ARES)
Ethernet POE switch with 16 gigabit Base-T ports and 2 gigabit optical ports (1 console port, 16 gigabit POE ports, 2 gigabit SFP ports, the standard AC220V power supply, 330W POE power, the cooling fan, 1U, standard 19-inch rack-mounted installation)
Produkto savybės:
Backplane:
64Gbps
Forwarding rate:
27Mpps
Dimensions:
440x232x45mm
Power consuption:
<45W
PoE Power:
330W
PoE/PoE+:
Support
Power supply:
AC: 100V-240V, 50Hz
Environment
Operating temperature/humidity: 0-50°C, 10-90% non-condensing
MAC exchange
Static configuration and dynamic MAC learning
MAC browsing and removal
Configurable aging time of the MAC address
Limited number of learnable MAC addresses
MAC filtration
VLAN
4K VLAN
GVRP
QinQ
Private VLAN
STP
802.1D (STP), 802.1W (RSTP) and 802.1S (MSTP)
BPDU protection, root protection, and loopback protection
Multicast
IGMP v1/v2/v3
IGMP Snooping
IGMP Fast Leave
Multicast group strategy and quantity limitation
Multicast flow copying over VLANs
IPv4
Static route, RIP v1/v2, OSPF, BGP
QoS
Flow classification based on L2~4 protocols
CAR flow limit
802.1P/DSCP priority re-labeling
SP, WRR, and “SP+WRR”
Congestion avoidance mechanisms like Tail-Drop and WRED
Flow monitoring and flow shaping
Security
L2/L3/L4 ACL flow identification and filtration
DDoS attack prevention, TCP’s SYN Flood attack prevention, UDP
Flood attack prevention, etc
Broadcast/multicast/unknown unicast storm-control
Port isolation
Port security, and “IP+MAC+port” binding (S2108POE does not support.)
DHCP Snooping and DHCP option 82 (S2108POE does not support the function.)
IEEE 802.1x authentication
Radius, BDTacacs+ authentication
Level-based command line protection
Reliability
Static/LACP link aggregation
EAPS and ERPS
ISSU uninterrupted system upgrade
Management
Console, Telnet, SSH2.0,
Web
SNMP v1/v2/v3
TFTP
RMON
Produkto specifikacijos:
-
Number of Fast Ethernet ports: 16
-
Management: Yes
-
LAN architecture: Fast Ethernet 10/100 Mb/s
-
Number of Gigabit ports: 2
-
Enclosure type: Rack
-
Switching layer: 2
-
Number of SFP ports: 2
-
Number of PoE ports: 16
-
Power: 400W
