EXTRALINK VFL, Fiber checker pen, fault locator, 5km range, 1mW (EL-FIBER-C-PEN)

Kodas: EL-FIBER-C-PEN
ID: #2340

1mw Fiber Fault Locator, Fiber Optic Tester, Fiber Optic Checker, 5km

21.49€ su PVM

Kaina be PVM: 17.76€

Kiekis:


Produkto savybės:

Fiber Fault Checker is a small and lightweight device that sends out a visible red laser. It can be used to check single and multi-module fiber optics very effectively. Connected to the fiber optic cable via fiber optic connector. The red laser can be used as a reference point and to locate the point where the fiber optic cable has crashed, which OTDR cannot find (fiber optic cable interruption; start and end) and the area of large bending losses.

It is ideal for passive components of patchcord fiber optic network, pigtail, fiber core box or bare fiber optic cable. These products are widely used in optical communication, optical transmission, fiber optic detection and other areas of research, manufacturing and construction. Checker can test not only single-mode fiber, but also multimode fiber.

  • High laser power output

  • Use simple "quick access" interface

  • Small size, light weight, high reliability

  • Battery-powered to facilitate the fiber connector

  • Access SM fiber and MM fiber highly efficient

Application:

  • Manufacture and research of optical components

  • Testing and Maintenance of Optical Equipments and Optical Networks

  • Teaching and experiment in optical communication

Produkto specifikacijos:

Emitter Type

F-PLD

Wavelength

650nm

Output Power

>=0.5mw

Output Way

Continuous output / 1 Hz modulation output

Optical Connector

Universal Interface and (FC, SC, ST adaptor)

Range

>=5KM

Power

Two 5# Batteries (LR6 Size AA 1.5V)
!!! NOT INCLUDED !!!

Operating Temperature

-10˚C + 60˚C

Storage Temperature

-20˚C + 70˚C

Battery Operating Time

15h

Dimension

L: 200mm Φ: 29mm

Weight

105g
