QuWireless QuSpot antena Teltonika RUTX11 maršrutizatoriui (QUSPOT_RUTX11)

Kodas: QUSPOT_RUTX11
ID: #1818

Integruota daugiajuostė LTE omni antena + WiFi omni antena + GPS antena + Bluetooth antena + vieta Teltonika RUTX11 maršrutizatoriui (viskas viename)

108.26€ su PVM

Kaina be PVM: 89.47€

  Turime sandėlyje
Kiekis:


Produkto savybės:

QuSpot omni LTE antenna for Teltonika RUTX11 router is a perfect outdoor device for mobile and fixed installations like industrial, CCTV, hotspots, yachts, boats, campers, RV etc. It also has embedded Wi-Fi dualband 2.4 & 5 GHz omni antenna, GPS antenna and Bluetooth antenna. If you use RUTX11 with QuSpot antenna, you get an integrated complete solution with embedded router and multi band antennas in one enclosure.

Produkto specifikacijos:

LTE Specifications:
• Frequency:
     * 0.694-0.96 GHz;
     * 1.7 - 2.2 GHz;
     * 2.2 - 2.7 GHz;
• Gain:
     * 2 dBi;
     * 2 dBi;
     * 4 dBi;
• VSWR:
     * <1.70, max <2.00;
     * <1.60, max <2.00;
     * <1.60, max <2.00;
• Beamwidth:
     * 360°/35° +/- 5°;
     * 360°/35° +/- 5°;
     * 360°/35° +/- 5°;
• Polarization: Vertical;
• Impedence: 50 Ω.

Wi-Fi Specifications:
• Frequency:
     * 2.40-2.50 GHz;
     * 4.70 - 6.00 GHz;
• Gain:
     * 6 dBi;
     * 7 dBi;
• VSWR:
     * <1.70, max <2.00;
     * <1.70, max <2.00;
• Beamwidth:
     * 360°/25° +/- 5°;
     * 360°/25° +/- 5°;
• Polarization: Vertical;
• Impedance: 50 Ω.

Mechanical Specification:
• Materials: ABS, aluminum, PTFE;
• Ingress Protection: IP67;
• Dimensions: 160 x 160 x 240 mm (6.3 x 6.3 x 9.45 inch);
• Weight: 1.5 kg (3.31 lbs);
• Operating Temperature: From -40°C to 75°C (From -40°F to 167°F).
