TP-LINK 16-prievadai Gigabit darbastalio komutatorius (TL-SG116)

Produkto savybės:

• 16 10/100/1000Mbps Auto-Negotiation RJ45 ports supporting Auto-MDI/MDIX
• Green Ethernet technology saves power consumption
• IEEE 802.3x flow control provides reliable data transfer
• Steel housing, desktop or wall-mounting design
• Support 802.1p/DSCP QoS and IGMP Snooping function
• Plug and play, with no configuration needed

Produkto specifikacijos:

HARDWARE FEATURES

Standards and Protocols: IEEE 802.3i, IEEE802.3u, IEEE802.3ab, IEEE802.3x, IEEE802.1p
Interface:
   16 x 10/100/1000Mbps Ports
   Auto-Negotiation, Auto-MDI/MDIX
Fan Quantity: Fanless
External Power Supply: External Power Adapter (Output: 12VDC / 1.0A)

LED Indicator:
   System Power
   Link/Act indicators per port built into each RJ-45 port

Dimensions ( W x D x H ): 286 x 112 x 25 mm (11.26 x 4.4 x 1.0 in.)
Max Power Consumption: 10W (220V/50Hz)
Max Heat Dissipation: 34.12BTU/h

PERFORMANCE

Packet Forwarding Rate: 23.8Mpps
MAC Address Table: 8K
Packet Buffer Memory: 4.1Mb
Jumbo Frame: 10KB

SOFTWARE FEATURES

Advanced Features:
   Green Technology
   802.3x Flow Control
   802.1p/DSCP QoS
   IGMP Snooping

Transfer Method: Store and Forward

OTHERS

Certification: CE, FCC ,RoHS

Package Contents:
   16-Port 10/100/1000Mbps Desktop Switch
   Power Adapter
   Installation Guide
   Rubber Feet

Environment:
   Operating Temperature: 0°C~40°C (32°F~104°F)
   Storage Temperature: -40°C~70°C (-40°F~158°F)
   Operating Humidity: 10% ~ 90%, non-condensing
   Storage Humidity: 5%~90% non-condensing
