Desktop komutatorius/šakotuvas TP-LINK TL-SG1008P, 8 Gigabit jungtys su 4 PoE jungtimis

Produkto savybės:

• 8 10/100/1000Mbps RJ45 ports;
• With four PoE ports, transfers data and power on one single cable;
• Supports PoE power up to 15.4W for each PoE port;
• Supports PoE power up to 53W for all PoE ports;
• Working with IEEE 802.3af compliant PDs, expands home and office network;
• Requires no configuration and installation.

Produkto specifikacijos:

Hardware Features:
• Interface: 8 10/100/1000Mbps RJ45 Ports
* AUTO Negotiation/AUTO MDI/MDIX;
• Network Media 0BASE-T: UTP category 3, 4, 5 cable (maximum 100m);
* EIA/TIA-568 100Ω STP (maximum 100m)
• 100BASE-TX: UTP category 5, 5e cable (maximum 100m);
* EIA/TIA-568 100Ω STP (maximum 100m)
• 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m);
* EIA/TIA-568 100Ω STP (maximum 100m)
• PoE Ports (RJ45)Standard: 802.3 af compliant;
• PoE Ports: Port1- Port4;
• Power Supply: 53W;
• Backbound Bandwidth:16Gbps;
• Mac Address Table: 8K;
• Buffer Size: 2Mbits;
• External Power Supply: External Power Adapter(Output: 48VDC / 1.25A);
• Dimensions (W X D X H): 6.7*3.9*1.1 in. (171*98*27 mm);
• Fan Quantity: Fanless.

Software Features:
• Transmission Method: Store-And-Forward;
• Advanced Functions: Compatible With IEEE 802.3af Compliant Pds;
• Priority Function;
• Mac Address Auto-Learning And Auto-Aging;
• IEEE802.3x Flow Control For Full-Duplex Mode And Backpressure For Half-Duplex Mode.

Others:
• Certification: FCC, CE, RoHS;
• Package Contents: TL-SG1008P, Power Adapter, User Guide;
• Consumption: 5.8 watts (max. no PD connected);
• 58.8 watts (max. with 53w PD connected);
• Environment: Operating Temperature: 0℃~40℃ (32℉~104℉);
• Storage Temperature: -40℃~70℃ (-40℉~158℉);
• Operating Humidity: 10%~90% non-condensing;
• Storage Humidity: 5%~90% non-condensing.
