TP-LINK 300Mbps Wireless N Ceiling Mount Access Point (EAP110)

OEM kodas: EAP110
Kodas: EAP110
ID: #1261

EAP Controller Software, Supports passive PoE, Captive portal for Wi-Fi guests, Multi-SSID, Enterprise class Wi-Fi security

naujiena
Kaina be PVM: Kaina su PVM (21%): Kainos lygis, kai užsakymo suma:
20.17€ 24.41€ >0€
20.07€ 24.28€ >100€
19.97€ 24.16€ >300€
Kiekis:
  Sandėlyje neturime


Produkto savybės:

Business Class Ceiling Mount Access Point

  • Free cloud centralized management and Omada app for ultra convenience and easy management
  • Supports passive PoE for convenient installation up to 100meters
  • Ceiling mounting design with chassis make it easy to deploy on a wall or ceiling
  • Secure guest network along with multiple authentication options (SMS/Facebook Wi-Fi/ Voucher, etc.) and abundant wireless security technologies
  • Multi-SSID divides multiple wireless networks for different users
  • Enterprise class Wi-Fi security help to decrease network security threats
  • Supports management vlan for an enhanced network management

Produkto specifikacijos:

HARDWARE FEATURES

Interface: Fast Ethernet (RJ-45) Port *1(Support Passive PoE)
Button: Reset
Power Supply: 24V Passive PoE (+4,5pins; -7,8pins. PoE Adapter Included)
Power Consumption: 2.8W
Dimensions: 7.5×6.8×1.2 in. (189.4×172.3×29.5mm)
Antenna Type: Internal 2* 4dBi Omni
Mounting: Ceiling /Wall Mounting (Kits included)

WIRELESS FEATURES

Wireless Standards: IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Frequency: 2.4-2.4835GHz

Signal Rate:
   11n: Up to 300Mbps(dynamic)
   11g: Up to 54Mbps(dynamic)
   11b: Up to 11Mbps(dynamic)

Reception Sensitivity:
   300M: -71dBm@10% PER
   150M: -75dBm@10% PER
   54M: -78dBm@10% PER
   11M: -93dBm@8% PER
   6M: -92dBm@10% PER
   1M: -96dBm@8% PER

Wireless Functions:
   Multiple SSIDs (Up to 8 SSIDs)
   Enable/Disable Wireless Radio
   Automatic Channel Assignment
   Transmit Power Control (Adjust Transmit Power on dBm)
   QoS(WMM)
   Rate Limit
   Reboot Schedule
   Wireless Schedule
   Wireless Statistics based on SSID/AP/Client

Wireless Security:
   Captive Portal Authentication
   Access Control
   Wireless MAC Address Filtering
   Wireless Isolation Between Clients
   SSID to VLAN Mapping
   Rogue AP Detection
   802.1X Support
   64/128/152-bit WEP / WPA / WPA2-Enterprise,WPA-PSK / WPA2-PSK

Transmission Power:
   CE: ≤19dBm(EIRP)
   FCC: ≤21dBm

MANAGEMENT

Omada Controller Software: Yes
Email Alerts: Yes
LED ON/OFF Control: Yes
Management MAC Access Control: Yes
SNMP: v1,v2c
System Logging Local/Remote Syslog: Local/Remote Syslog
Telnet: Yes
Web-based Management: HTTP/HTTPS
Management VLAN: Yes

OTHERS

Certification: CE, FCC, RoHS

Package Contents:
   300Mbps Wireless N Ceiling Mount Access Point EAP110
   Passive PoE Adapter
   Power Cord
   Mounting Kits
   Installation Guide

System Requirements: Microsoft Windows 10/8/7/Vista/XP

Environment:

   Operating Temperature: 0℃~40℃ (32℉~104℉)
   Storage Temperature: -40℃~70℃ (-40℉~158℉)
   Operating Humidity: 10%~90% non-condensing
   Storage Humidity: 5%~90% non-condensing

Papildoma informacija apie produktą:

Datasheet
Quick Installation Guide
Link to manufacturer product page
