TP-LINK apkrovos balanso plačiajuosčio ryšio maršrutizatorius (TL-R470T+)

Produkto savybės:

• Up to 4 WAN ports equipped with advanced load balance to guarantee maximum bandwidth and backup capabilities
• Provides extensive client account and network management for administrators with supported PPPoE Server
• Marshals bandwidth resource to specific clients based on their unique application environments
• Smaller case for cost-effective solution in the small office or Internet cafes network

Produkto specifikacijos:

HARDWARE FEATURES

Standards and Protocols: IEEE 802.3, 802.3u, 802.3x, TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP, HTTP, DDNS

Interface:
   1 Fixed Ethernet WAN Port
   1 Fixed Ethernet LAN Port
   3 Changeable Ethernet WAN/LAN Ports

Network Media: 10BASE-T: UTP category 3, 4, 5 cable (Max 100m), 100BASE-TX: UTP category 5, 5e cable (Max 100m)
Button: Reset Button
Power Supply: External 9V/0.6A DC Adapter
Flash: 16MB
DRAM: 64MB
LED: PWR, SYS, WAN, LAN, WAN/LAN
Dimensions ( W x D x H ): 8.2*5.0*1.0in. (209*126*26mm)


PERFORMANCE

Concurrent Session: 10000

BASIC FUNCTIONS

WAN Connection Type: Static/Dynamic IP, PPPoE, PPTP, L2TP, Dual Access, Bigpond Cable
DHCP: DHCP Server/Client, DHCP Address Reservation
MAC Clone: Modify WAN/LAN MAC Address
Switch Setting: Rate Control, Port Configuration, Port VLAN

ADVANCED FUNCTIONS

ACL: IP/MAC/URL/WEB Filtering
IGMP: IGMP Proxy/IGMP Snooping
Forwarding: Virtual Server, Port Triggering, DMZ
Load Balance: Policy Routing, Link Backup
Routing: Static Routing
Security: FTP/SIP/PPTP/IPsec/H.323 ALG, DoS Defence, Ping of Death, IP/MAC Binding
Traffic Control: Bandwidth Control, Session Limit

MANAGEMENT

Service: PPPoE Server, E-Bulletin, Dynamic DNS, UPnP
Maintenance: Time Setting, Daylight Saving Time, SNMP, Diagnostics, Firmware Upgrade, Factory Defaults/Reboot, Backup/Restore, System Log, Remote Management, Statistics

OTHERS

Certification: CE, FCC, RoHS

Package Contents:
   TL-R470T+
   Power Adapter
   RJ-45 Ethernet Cable
   Quick Installation Guide

System Requirements: Microsoft® Windows® 8, 7,Vista™, XP or MAC® OS, NetWare®, UNIX® or Linux

Environment:
   Operating Temperature: 0℃~40℃ (32℉~104℉)
   Storage Temperature: -40℃~70℃ (-40℉~158℉)
   Operating Humidity: 10%~90% non-condensing
   Storage Humidity: 5%~90% non-condensing
