UBIQUITI 2.5G PoE++ Adapter, 30W (UACC-PoE+-2.5G)

Produkto savybės:

An adapter that can power UniFi PoE+ devices, reduce dependency on PoE switch power, and provide a Multi-Gigabit LAN connection.

- Delivers up to 30W of PoE+

- Surge, peak pulse, and overcurrent protection

- Contains RJ45 data input, AC cable with earth ground, and PoE+ output

- LED indicator for status monitoring

Produkto specifikacijos:

Dimensions: 93 x 62 x 35 mm (3.7 x 2.4 x 1.4")
Weight: 156 g (5.5 oz)
Output Voltage: 48V DC @ 0.65A
Rated Voltage: 100—240V AC @ 50/60Hz
Gigabit LAN Port: Yes
2-pair Powering: Pins 4, 5 (+) and 7, 8 (-)
Clamping Protection: 11V Data, 60V power
Data In / PoE: RJ45 Shielded Socket
Input Current: 0.75A Max.
Inrush Current: <150A peak @ 230V AC
Efficiency: >87%
Switching Frequency: 65 kHz Max.
Output Ripple: 1% Max.
Line Regulation: ≤ 1%
Load Regulation: ≤ 3%
Max. Surge Discharge: 1500A (8/20 μs) power
Peak Pulse Current: 36A (10/1000 μs) data
Response Time: <1 ns
Shunt Capacitance: <5 pF data
Surge Protection: Difference and Common Mode
Ambient Storage Temperature: -30 to 70°C (-22 to 158° F)
Ambient Operating Temperature: 0 to 40° C (32 to 104° F)
Ambient Operating Humidity: 10 to 95% Falsencondensing|
NDAA Compliant: Yes
Certifications: CE, FCC, IC, UL, UKCA, KC, CCC, RoHS
