UBIQUITI 24 Ports Gigabit PoE Switch Pro Gen2 (USW-Pro-24-PoE)

Kodas: USW-Pro-24-PoE
ID: #2093

The USW-Pro-24-POE is a configurable Gigabit Layer2 and Layer3 switch with auto-sensing 802.3at PoE+ and 802.3bt PoE++. Sixteen PoE+ and eight PoE++ RJ45 ethernet ports have total 400W PoE budget, and two SFP+ ports offer 10Gbps uplink options. Near-silent cooling and a 1.3" touch LCM

741.83€ su PVM

Kaina be PVM: 613.08€

Kiekis:


Produkto savybės:

Build and expand your network with the UniFi® Switch, part of the Ubiquiti Networks® UniFi Enterprise System. The UniFi Switch PRO 24 PoE, is a configurable Gigabit Layer-3 switch with auto-sensing 16 802.3at PoE+ and 8 802.3bt PoE++. It offers 24 RJ45 Ethernet ports and 2 SFP+ ports, providing 10 Gigabit PoE links to your devices and fiber uplink options to your enterprise network.

The UniFi Switch PRO 24 PoE features an 1.3" touch LCM and integrated fans for quiet cooling. The LCM provides current switch states and the neccessary information you need for quick diagnosis.

Managed and configured by the UniFi Controller with UniFi Mobile app support, the UniFi Switch offers an extensive suite of advanced Layer-3 switching protocols and features, including operation mode (switching, mirroring, or aggregate) per port, Inter-VLAN routing, static routing and DHCP server. The UniFi Controller and mobile app allows admins to configure and monitor virtually all of the switch features in a graphical user interface from anywhere.

Note: Layer3 will be included in later software release

Produkto specifikacijos:

Dimensions 442.4 x 285.4 x 43.7 mm
(17.42 x 11.24 x 1.72")
Weight
With Rackmount Brackets
4.30 kg (9.48 lb)
4.39 kg (9.68 lb)
Interfaces
Networking

Management
(24) 10/100/1000 RJ45 Ports
(2) 1/10G SFP+ Ethernet Ports

Ethernet In-Band
Power Method
Universal Input
USP RPS DC Input

100-240VAC/50-60 Hz
52VDC, 7.69A; 11.5VDC, 2.61A
Power Supply AC/DC, Internal, 450W
Supported Voltage Range 100 to 240VAC
Max. Power Consumption (Excluding PoE Output) 50W
LEDs
System
RJ45 Data Ports
SFP Data Ports

Status
PoE; Speed/Link/Activity
Link/Activity
ESD/EMP Protection Air: ± 16 kV, Contact: ± 12 kV
Shock and Vibration ETSI300-019-1.4 Standard
Operating Temperature -5 to 40° C (23 to 104° F)
Operating Humidity 10 to 90% Noncondensing
Certifications CE, FCC, IC
Sound Level*
25% PoE Load, 25° C Room Temperature 0.9 dBr
50% PoE Load, 25° C Room Temperature 7.3 dBr
100% PoE Load, 40° C 18.8 dBr
PoE
PoE Interfaces
Ports 1-16
Ports 17-24

POE+ IEEE 802.3af/at, (pins 1, 2+; 3, 6-)
60W PoE++ IEEE 802.3bt, (Pair A 1, 2+; 3, 6-) (Pair B 4 , 5+; 7, 8-)
Max. PoE Wattage per Port by PSE
802.3at
802.3bt

32W
64W
Voltage Range 802.3af Mode 44-57V
Voltage Range 802.3at Mode 50-57V

*Background noise level: 27.5 dBa
