UBIQUITI EdgeRouter 12P (ER-12P)

Kodas: ER-12P
ID: #2278

10x Gigabit RJ45 routing ports | All LAN ports with 24V Passive PoE-out | 2x SFP ports | Ports 0-7 can be configured for line-rate Layer 2 switching | Silent, fanless operation | Compact, durable metal case | Wall or rack-mountable

323.41€ su PVM

Kaina be PVM: 267.28€
Kiekis:

Sandėlyje neturime

Pranešti, kai turėsime prekę

Papildoma informacija apie produktą:

Brošiūra
Trumpas naudotojo vadovas
Nuoroda į produkto aprašymą gamintojo svetainėje
CE deklaracija



Produkto savybės:

The EdgeRouter 12P is a high performance Gigabit Router with 24V 2-Pair PoE output on each port. With increased performance over the previous generation of routers, the EdgeRouter 12P delivers up to 3.4 million pps for 64-byte packets. Ten Gigabit Ethernet ports offer copper connectivity, while two SFP ports offer fiber connectivity. The EdgeRouter 12P supports Layer-2 switching and scalable configuration using EdgeOS or the Ubiquiti Network Management System (UNMS).

Features

  • (10) Gigabit RJ45 routing ports
  • 24V PoE support on RJ45 ports
  • Ports 0-7 can be configured for line-rate Layer 2 switching
  • (2) Gigabit SFP ports
  • 3.4 million packets per second for 64-byte packets
  • 6.8 Gbps for packets 1518 bytes or larger in size
  • Silent, fanless operation
  • Compact, durable metal case
  • Wall or rack-mountable*

* Rack-mount sold separately

Produkto specifikacijos:

EdgeRouter 12P
Dimensions 268.1 x 136.5 x 31.1 mm (10.55 x 5.37 x 1.22")
Weight 700 g (1.54 lb)
Max. Power Consumption 20W (Excludes PoE Output)
Power Method External AC/DC Power Adapter, 12W (24V, 2.5A) (Included)
Power Supply External AC/DC Adapter
Supported Voltage Range 9 - 30VDC
Button Reset
LEDs Data Ports: Speed/Link/Activity, PoE
SFP Data Port: Link/Activity
Networking Interfaces Management: (1) RJ45 Serial Port, (10) Ethernet Ports (Default Port 0)
Networking: (10) 10/100/1000 RJ45 Ports with PoE, (2) 1 Gbps SFP Ports
Layer 3 Forwarding Performance Packet Size: 64 Bytes - 3,400,000 pps
Packet Size: 1518 Bytes or Larger - 6.8 Gbps (Line Rate)
Processor 4-Core 1 GHz, MIPS64
System Memory 1 GB DDR3 RAM
On-Board Flash Storage 4 GB eMMC, 8 MB SPI NOR
Mounting Wall, Rack (With optional Rack Mount Kit, model ER-RMKIT)
Operating Temperature -10 to 40° C (14 to 104° F)
Operating Humidity 10 - 90% Noncondensing
Certifications CE, FCC, IC
PoE with 24VDC Power Adapter
PoE Interfaces (10) 24V Passive PoE Ports, 2-pair (4, 5+; 7, 8-)
Passive PoE Max. Wattage Per Port 17W (24V)
Voltage Range Passive PoE 24V: 20 to 30V
