UBIQUITI UniFi Protect Network Video Recorder (UNVR)

OEM kodas: UNVR
Kodas: UNVR
ID: #2405

4x 2.5"/3.5" Drive bays | 1x 10G SFP+ port | 1x Gigabit RJ45 port | 1U rackmountable (kit included) | Supports USP-RPS for PSU failover | up to 30 days of 4K video storage for 15 cameras or Full HD video storage for 50 cameras

347.29€ su PVM

Kaina be PVM: 287.02€

Kiekis:


Produkto savybės:

The UniFi® NVR is an enterprise network video recorder that integrates an NVR, the UniFi Protect software, and a 4-drive bay. UNVR unifies enterprise-class data protection and scalable storage with simple Plug and Play integration using the intuitive UniFi Protect software. From a desktop computer or mobile device, you can access your surveillance recordings from virtually anywhere using the intuitive graphical user interface. The mobile app is available for iOS and Android-based devices. The drive bays are easily accessed from the front panel, so hard drive mounting and maintenance are simple. Using four 8 TB drives in a RAID 5 configuration, the UNVR can provide up to 30 days of 4k video storage for 15 cameras or Full HD video storage for 50 cameras.

- (4) 2.5"/3.5" Drive bays
- (1) 10G SFP+ port
- (1) Gigabit RJ45 port
- 1U rackmountable (kit included)
- Plug and Play UniFi Protect system with NVR
- Automated secure RAID 1 or RAID 5 configuration
- Supports USP-RPS for PSU failover

Produkto specifikacijos:

Dimensions 442.4 x 325 x 43.7 mm
(17.4 x 12.8 x 1.7")
Weight
Without Rackmount Brackets
With Rackmount Brackets

5.11 kg (11.27 lb)
5.20 kg (11.46 lb)
Enclosure Characteristics SGCC Steel
Processor Quad-Core ARM Cortex-A57 at 1.7 GHz
System Memory 4 GB DDR4
On-Board Flash Storage SPI NOR 32 MB, USB Flash 8 GB
Max. Power Consumption 100W
Max. Power Budget for Drives 75W
Power Method (1) Universal AC Input
(1) RPS DC Input
Power Supply 100-240VAC, 50/60 Hz, 2A
Networking Interfaces (1) 10/100/1000 Mbps RJ45 Ethernet
(1) 1/10 Gbps SFP+ Ethernet
Management Interface Ethernet In-Band Management
ESD/EMP Protection Air: ± 12kV, Contact: ± 8kV
Operating Temperature -5 to 40° C (23 to 104° F)
Operating Humidity 5 - 95% Noncondensing
LEDs
System



Ethernet
SFP+ White
SFP+
HDD

(1) Power, Blue/White
Flashing White: Bootup in Progress
Flashing Blue: Firmware Upgrading
Steady White: Factory Defaults, Awaiting Adoption
Steady Blue: Device is Adopted
Green: 1000 Mbps, Amber: 10/100 Mbps
White: 10 Gbps, Green: 1 Gbps
Amber: Disk Error, White: Disk Detected
