UBIQUITI UniFi Aggregation Switch (USW-Aggregation)

OEM kodas: USW-Aggregation
Kodas: USW-Aggregation
ID: #3050

8x 10G SFP+ Ports | 1.3" Touchscreen with AR switch management | Fanless | Layer 2

256.23€ su PVM

Kaina be PVM: 211.76€

Kiekis:


Produkto savybės:

UniFi Aggregation Switch is a managed Layer 2 switch with eight 10G SFP+ ports. Featuring a compact 4.7" depth and fanless design, it supports high-bandwidth links to provide link aggregation for higher capacity and increased availability.

Features:

Managed by UniFi Network Controller version: 5.14.12 or higher.

    • (8) 10G SFP+ Ports
    • 160 Gbps switching capacity
    • 1.3" Touchscreen with AR switch management
    • Fanless, 4.7" depth compact enclosure
    • 1U Rackmountable (kit included)
    • Managed by UniFi Network Controller

Works with UniFi Network Controller

  • Manage your networks from a single interface.
  • Enjoy intuitive configuration options, as well as robust device control and monitoring.
  • Upgrade device firmware remotely.
  • Easily manage network users and guests.
  • Personalize the design, architecture, and privacy of guest hotspots.

Produkto specifikacijos:

Mechanical
Dimensions 442.4 x 120 x 43.7 mm (17.42 x 4.72 x 1.72")
Weight
Without Mount
With Mount

2.65 kg (5.84 lb)
2.74 kg (6.04 lb)
Enclosure Material SGCC Steel
Hardware
Total Non-Blocking Throughput 80 Gbps
Switching Capacity 160 Gbps
Forwarding Rate 119.04 Mpps
Max. Power Consumption 30W
Power Method Universal AC Input: 100-240VAC, 50/60 Hz
Power Supply AC/DC, Internal, 36W
Management Interface Ethernet In-Band
Modes SMB Layer 2 Gigabit Ethernet Switch
ESD/EMP Protection Air: ± 16kV, Contact: ± 12kV
Operating Temperature -5 to 40° C (23 to 104° F)
Operating Humidity 10 - 90% Noncondensing
Certifications CE, FCC, IC
LED
System
(1) Bootup Animation
Firmware Upgrade Icon
Steady White
Steady Blue
SFP+

Bootup in Progress
Firmware Upgrading
Factory Defaults, Awaiting Adoption
Device is Adopted
White: 10G, 1G
