UBIQUITI CRM point (CRM-P)
UBIQUITI CRM point, CRM-P - Central management of AirMAX devices, Qual-Core SoC CPU, 2GB RAM, 1 x Gbit Lan, 1 x microSD, 802.3af Poe
Produkto savybės:Ubiquiti Networks introduces the CRM Point™, a compact, locally hosted solution for management of your airMAX® and airMAX ac network devices from a central point.
• Plug and play
• Breakthrough size and performance
• Powerful quad-core architecture
• Versatile scalability
• No hosting fees
Instant setup – just connect the CRM Point to 802.3af PoE and run the U CRM Control™ setup wizard.
Pocket-sized for a minimal footprint, the CRM Point can easily be plugged into any switch or router on your network.
Featuring a quad-core processor, the CRM Point provides top-level processing power for centralized device management.
The CRM Point scales to host networks of almost any size to meet your growing management needs.
The U CRM Control software and all of its data are stored locally on the CRM Point, eliminating the costs associated with third-party cloud storage.
Software - U CRM Control.
The U CRM Control software comes pre-installed on the CRM Point for immediate deployment. The software provides an intuitive user interface with powerful features for advanced network and device management. Using the U CRM Control software, you can now manage groups of airMAX and airMAX ac devices from anywhere in the network.
U CRM Control lets you quickly discover all airMAX and airMAX ac devices within your network. In addition to automatic device discovery, you can also scan IP ranges or manually add devices using their IP addresses.
Check the system dashboard to display a summary of the current network status and to get real-time updates on the network status. The dashboard shows the PtP and PtMP
networks. For each network type, you can display the spectral efficiency, airtime, and radio distribution for all applicable frequency bands. Real-time graphs also display throughput or airtime statistics.
Track network performance with summary and detailed device views. Monitor uplink and downlink statistics, including charts of wireless signal quality and device activity. Search for a specific device or use filters to quickly find the devices you’re looking for.
Batch Firmware Upgrades
The U CRM Control software allows you to upgrade firmware simultaneously on multiple airMAX and airMAX ac devices, saving you valuable time.
The powerful link simulator helps you to plan your deployments. Create a point-to-point simulation anywhere on the map and test the link performance with immediate feedback based on terrain data and device configuration.
Produkto specifikacijos:Dimensions: 21.7 x 43.4 x 121.9 mm (0.85 x 1.71 x 4.80")
Weight: 110 g (3.88 oz)
Max. Power Consumption: 5W
Power Method PoE: 48V 802.3af or Passive PoE (Pairs 4, 5+; 7, 8 Return)
Power Method Micro-USB: 5V
Power Supply: 802.3af PoE or Micro-USB 5V, 1A
Operating Temperature: 0 to 40° C (32 to 104° F)
Operating Humidity: 20 to 90% Noncondensing
Processor: Qual-Core SoC
System Memory: 2 GB DDR3
Ports Networking Interface: (1) 10/100/1000 RJ45 Port
Ports Memory Interface: (1) microSD Port
LED: Factory Defaults/Device Busy/Device Working
Certifications: CE, FCC, IC
