UBIQUITI UniFi AC In-Wall AP (UAP-AC-IW)

Kodas: UAP-AC-IW
ID: #1215

UBIQUITI UniFi AC In-Wall AP, UAP-AC-IW, up to 1167 Mbps in Wall AP/Hotspot 5 Ghz and 2,4 GHz, 802.11 a/b/g/n/ac, 2x Gbit LAN, up to 250+ clients - indoor - POE unit is not included in package

98.91€ su PVM

Kaina be PVM: 81.74€

Kiekis:


Produkto savybės:

The UniFi AC In-Wall AP transforms an Ethernet wall connection into a dual-band 802.11AC Wi-Fi Access Point. It features two Gigabit Ethernet ports, one of which delivers PoE to power and  onnect an 802.3af device to the network. The UniFi AC In-Wall AP provides simultaneous, dual-band, 2x2 MIMO technology and is available in single- and five-packs*.

* We recommend powering the UniFi AC In-Wall and In-Wall Pro APs with the UniFi PoE Switch, as PoE adapters are not included.

Produkto specifikacijos:

Dimensions: 139.7 x 86.7 x 25.75 mm (5.5 x 3.41 x 1.01")

Weight: 200 g (6.43 oz)

Networking Interface: (3) 10/100/1000 Ethernet Ports

Buttons(s): Reset

Power Method: 802.3at PoE+ Supported

Power Supply: UniFi PoE Switch (Not Included)

Power Save: Supported

PoE Out: 48V Pass-Through (Pins 1, 2+; 3, 6-)

Maximum Power Consumption: 7W
     with PoE Passthrough -  19W*

Maximum TX Power:
2.4 GHz - 20 dBm
5 GHz - 20 dBm

MIMO:
2.4 GHz - 2 x 2
5 GHz - 2 x 2

Max. Data Speed:
2.4 GHz - 300 Mbps
5 GHz - 867 Mbps

Max. Range: 100 m (328')

Antennas: 2 x  Dual-Band Antenna, Single-Polarity

Antenna Gain:
2.4 GHz - 1 dBi
5 GHz - 2 dBi

Wi-Fi Standards: 802.11 a/b/g/n/ac

Wireless Security: WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES)

BSSID: Up to Four per Radio

Mounting: 1-Gang Electrical Wall Box (Not Included)

Operating Temperature: -10 to 50° C (14 to 122° F)

Operating Humidity: 5 to 95% Noncondensing

Certifications: CE, FCC, IC

* Requires 802.3at PoE+ switch

ADVANCED TRAFFIC MANAGEMENT

VLAN: 802.1Q
Advanced QoS: Per-User Rate Limiting
Guest Traffic Isolation: Supported
WMM: Voice, Video, Best Effort, and Background
Concurrent Clients: 250+

SUPPORTED DATA RATES (Mbps)

802.11ac - 6.5 Mbps to 867 Mbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80)
802.11n - 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
802.11a - 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11g - 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b - 1, 2, 5.5, 11 Mbps
